| 图片 | 型号 | 库存 | 价格 | 数量 | 规格书 | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ESC107M035AG3EACAP ALUM 100UF 20% 35V RADIAL |
11,696 | 0.37 |
立即询盘 |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | ESC | Active | 100 µF | ±20% | 35 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 315 mA @ 120 Hz | 450 mA @ 100 kHz | 140 mOhms | 0.138 (3.50mm) | 0.315 Dia (8.00mm) | 0.492 (12.50mm) | - | Through Hole |
|
EDH107M016A9GAACAP ALUM 100UF 20% 16V SMD |
14,676 | 0.43 |
立即询盘 |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | EDH | Active | 100 µF | ±20% | 16 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 71 mA @ 120 Hz | 88.75 mA @ 10 kHz | - | - | 0.248 Dia (6.30mm) | 0.222 (5.65mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
EDK226M025A9GAACAP ALUM 22UF 20% 25V SMD |
11,763 | 0.43 |
立即询盘 |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | EDK | Active | 22 µF | ±20% | 25 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 55 mA @ 120 Hz | 68.75 mA @ 10 kHz | - | - | 0.248 Dia (6.30mm) | 0.222 (5.64mm) | 0.260 L x 0.307 W (6.60mm x 7.80mm) | Surface Mount |
|
EEV106M025A9BAACAP ALUM 10UF 20% 25V SMD |
13,122 | 0.47 |
立即询盘 |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | EEV | Active | 10 µF | ±20% | 25 V | 1.93Ohm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 63 mA @ 120 Hz | 90 mA @ 100 kHz | 1.93 Ohms | - | 0.157 Dia (4.00mm) | 0.222 (5.65mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
|
EEV106M035A9BAACAP ALUM 10UF 20% 35V SMD |
14,328 | 0.47 |
立即询盘 |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | EEV | Active | 10 µF | ±20% | 35 V | 1.93Ohm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 63 mA @ 120 Hz | 90 mA @ 100 kHz | 1.93 Ohms | - | 0.157 Dia (4.00mm) | 0.222 (5.65mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
|
EEV107M016S9GAACAP ALUM 100UF 20% 16V SMD |
10,765 | 0.46 |
立即询盘 |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | EEV | Active | 100 µF | ±20% | 16 V | 520mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 168 mA @ 120 Hz | 240 mA @ 100 kHz | 520 mOhms | - | 0.248 Dia (6.30mm) | 0.222 (5.65mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
ESL105M100AC3AACAP ALUM 1UF 20% 100V RADIAL |
11,654 | 0.22 |
立即询盘 |
Datasheet |
Bulk | ESL | Active | 1 µF | ±20% | 100 V | 1.85Ohm @ 100kHz | 8000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 52.5 mA @ 120 Hz | 105 mA @ 100 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.492 (12.50mm) | - | Through Hole |
|
|
EEV227M016S9HAACAP ALUM 220UF 20% 16V SMD |
12,397 | 0.49 |
立即询盘 |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | EEV | Active | 220 µF | ±20% | 16 V | 220mOhm @ 100kHz | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 196 mA @ 120 Hz | 280 mA @ 100 kHz | 220 mOhms | - | 0.248 Dia (6.30mm) | 0.315 (8.00mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
EDT226M035S9HAACAP ALUM 22UF 20% 35V SMD |
14,475 | 0.50 |
立即询盘 |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | EDT | Active | 22 µF | ±20% | 35 V | - | 1000 Hrs @ 125°C | -40°C ~ 125°C | Polar | AEC-Q200 | Automotive | 70 mA @ 120 Hz | 100 mA @ 100 kHz | - | - | 0.248 Dia (6.30mm) | 0.315 (8.00mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
|
EDK227M016A9HAACAP ALUM 220UF 20% 16V SMD |
14,696 | 0.51 |
立即询盘 |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | EDK | Active | 220 µF | ±20% | 16 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 162 mA @ 120 Hz | 202.5 mA @ 10 kHz | - | - | 0.248 Dia (6.30mm) | 0.315 (8.00mm) | 0.260 L x 0.307 W (6.60mm x 7.80mm) | Surface Mount |
|
EXV226M035A9DAACAP ALUM 22UF 20% 35V SMD |
10,883 | 0.57 |
立即询盘 |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | EXV | Active | 22 µF | ±20% | 35 V | - | 3000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 112 mA @ 120 Hz | 160 mA @ 100 kHz | 1 Ohms | - | 0.197 Dia (5.00mm) | 0.222 (5.65mm) | 0.209 L x 0.209 W (5.30mm x 5.30mm) | Surface Mount |
|
ESC227M035AH1EACAP ALUM 220UF 20% 35V RADIAL |
10,511 | 0.51 |
立即询盘 |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | ESC | Active | 220 µF | ±20% | 35 V | 690mOhm @ 100kHz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 560 mA @ 120 Hz | 800 mA @ 100 kHz | 69 mOhms | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.531 (13.50mm) | - | Through Hole |
|
ESK107M063AH1EACAP ALUM 100UF 20% 63V RADIAL |
10,200 | 0.51 |
立即询盘 |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | ESK | Active | 100 µF | ±20% | 63 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | - | - | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.531 (13.50mm) | - | Through Hole |
|
|
EXV106M050A9GAACAP ALUM 10UF 20% 50V SMD |
14,465 | 0.54 |
立即询盘 |
Datasheet |
Tape & Reel (TR),Cut Tape (CT) | EXV | Active | 10 µF | ±20% | 50 V | - | 3000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 98 mA @ 120 Hz | 140 mA @ 100 kHz | 2.6 Ohms | - | 0.248 Dia (6.30mm) | 0.222 (5.65mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
ESH105M100AC3AACAP ALUM 1UF 20% 100V RADIAL |
11,005 | 0.26 |
立即询盘 |
Datasheet |
Bulk | ESH | Active | 1 µF | ±20% | 100 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 15 mA @ 120 Hz | 22.5 mA @ 100 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.492 (12.50mm) | - | Through Hole |
|
|
ESK477M025AH1EACAP ALUM 470UF 20% 25V RADIAL |
13,466 | 0.52 |
立即询盘 |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | ESK | Active | 470 µF | ±20% | 25 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | - | - | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.531 (13.50mm) | - | Through Hole |
|
|
ESK227M050AH1EACAP ALUM 220UF 20% 50V RADIAL |
10,642 | 0.50 |
立即询盘 |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | ESK | Active | 220 µF | ±20% | 50 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | - | - | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.531 (13.50mm) | - | Through Hole |
|
ESL106M100AE3AACAP ALUM 10UF 20% 100V RADIAL |
11,677 | 0.29 |
立即询盘 |
Datasheet |
Bulk | ESL | Active | 10 µF | ±20% | 100 V | 680mOhm @ 100kHz | 8000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 140 mA @ 120 Hz | 280 mA @ 100 kHz | - | 0.098 (2.50mm) | 0.248 Dia (6.30mm) | 0.492 (12.50mm) | - | Through Hole |
|
ESE227M050AH2EACAP ALUM 220UF 20% 50V RADIAL |
11,524 | 0.57 |
立即询盘 |
Datasheet |
Cut Tape (CT),Tape & Box (TB) | ESE | Active | 220 µF | ±20% | 50 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 340 mA @ 120 Hz | 425 mA @ 10 kHz | - | 0.197 (5.00mm) | 0.394 Dia (10.00mm) | 0.669 (17.00mm) | - | Through Hole |
|
ESK106M035AC3AACAP ALUM 10UF 20% 35V RADIAL |
14,697 | 0.19 |
立即询盘 |
Datasheet |
Bulk | ESK | Active | 10 µF | ±20% | 35 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 60 mA @ 120 Hz | 90 mA @ 10 kHz | - | 0.079 (2.00mm) | 0.197 Dia (5.00mm) | 0.492 (12.50mm) | - | Through Hole |
